Coating Thickness Gauge NOVOTEST TP-2020
Digital coating thickness measurement gauge
Key Features
- Dual measurement methods (magnetic + eddy current)
- Automatic substrate detection (Fe/NFe)
- High accuracy and resolution
- Wide measurement range up to 2000 µm
- Compact and lightweight design
- Large LCD display with backlight
- Statistical analysis (average
- min
- max
- std dev)
- Data storage for 400 measurements
- USB connectivity for data transfer
- Calibration foils included
- Low battery consumption
- Auto power-off function
Technical Specifications
| Measurement Methods | Magnetic induction (Fe) + Eddy current (NFe) |
| Measurement Range | 0-2000 µm (Fe), 0-2000 µm (NFe) |
| Accuracy | ±(3% + 1 µm) |
| Resolution | 0.1 µm (0-99.9 µm), 1 µm (=100 µm) |
| Min. Substrate Thickness | 0.5 mm |
| Min. Measurement Area | 6 mm diameter |
| Display | LCD with backlight |
| Memory | 400 measurements |
| Interface | USB |
| Power Supply | AAA batteries |
| Operating Time | Up to 50 hours |
| Weight | 95g (with batteries) |
| Dimensions | 110 x 50 x 25 mm |
Applications
Paint thickness measurement on vehicles
Powder coating quality control
Galvanizing thickness verification
Anodizing layer measurement
Protective coating inspection
Manufacturing quality assurance
Corrosion protection verification
Automotive refinishing inspection
Aerospace coating measurement
Marine coating inspection
